VME

MODULAR AND CONFIGURABLE

The VME-CPCI Series, Configurable Power Supply line allows users to configure a unit based upon “Off the Shelf” sub-modules and options. It’s as easy as choosing your input voltage front end requirements, output voltage specifications and options, and Arnold Magnetics does the rest. We deliver a complete plug and play unit, in a fraction of the time it takes for custom products!

  • 3.3V, 5V, ±12V and 24V DC outputs
  • 28VDC, 115VAC( Single and 3 Phase) Input
  • Output power up to 500W
  • 6U & 3U models in 4HP & 8HP case widths
  • Myriad of Options available
  • Mil-Std-461 Filter (Optional)
  • Mil-Std-704 and 1399 Transients (Optional)
  • Mil-Std-810 Severe Environments
Product DatasheetCONFIGURATOR

Summary Specifications

  • AC Input Voltage Ranges Contact factory for special needs.115VAC, Single Phase, 50/60Hz, 400Hz 115VAC L-N/200VAC L-L , 3 Phase Wye, 50/60/400Hz 115VAC L-L, 3 Phase Delta, 50/60Hz
  • DC Input Voltage Ranges Contact factory for special needs.18-36VDC, 36-72VDC, 115VDC, 155VDC, 270VDC
  • Output Voltage(s)Any voltage, 3.3V, 5V, ±12V, ±15V, 24V, 28V
  • Output Power – typical Contact factory for special needs.Up to 500W (AC input) or up to 600W (DC input)
  • Options Contact factory for special needs.Mil-Std-461 EMI Filter, On/Off Control, Thermal Shutdown, BIT/Fault Summary, Inrush Control, Hold-up Time, Mil-Std-704 & 1399 Transient Protection, Panel LED display(s), Redundant Operation, Low Noise Output Filters
  • Case Sizes – typical Contact factory for special needs.Range from 0.78”H x 6.58”D x 4.45”L to 1.58”H x 6.58”D x 9.18”L” with wide variety of styles & mounting available
  • I/O Options – typicalMil grade type (std), Power D-Sub, Euro-DIN type
  • Operating EnvironmentsMil-Std-810F ( See Data Sheet )
  • Operating Temperature-40C to +85C, baseplate (Conduction Cooled) -55C to +85C (Optional)

Proven Off The Shelf Technology

  • Low Program Risk
  • Quick Delivery
  • Light Weight
